| Sistem Projector | DLP Technology |
| Resolusi Native | WUXGA (1920 x 1200) |
| Brightness | 8000 Lumens |
| Rasio Kontras | 100,000:1 |
| Rasio Aspek | - Native 16:10 {5:4/4:3/16:10/16:9/1.88/2.35/Theaterscope/Source(Auto)/Unscaled(Real) selectable}
|
| Rasio Besaran (Zoom) | - Ultra Short Throw (5J.JCY37.001) : Fixed
- Wide Fix (5J.JAM37.011) : Fixed
- Ultra Wide (5J.JAM37.061) : 1.25:1
- Wide Zoom (5J.JAM37.021) : 1.41:1
- Standard (5J.JAM37.001) : 1.3:1
- Semi Long (5J.JAM37.051) : 1.65:1
- Long Zoom1 (5J.JAM37.031) : 1.5:1
- Long Zoom 2 (5J.JAM37.041) : 1.55:1
|
| Ukuran Gambar | - Diagonal : 80"-500" (Standard lens)
|
| Input | - Computer 1 in (D-sub 15pin)x 1
- Computer 2 in (5BNC, R/G/B/H/V)x 1
- HDMI (1.4a) x 1 (Compatible with HDCP)
- DVI-D in x 1 (Compatible with HDCP)
- LAN (RJ45) x 1 (LAN Control)
- 3G-SDI x 1 (Input/Output)
- HDBaseT x 1 (Shared with RJ45)
- DisplayPort x 1
- Trigger x 1
- RS232 (DB-9pin) x 1
- Wired Remote x 1
- IR Receiver x 2 (Front Rear)
|
| Output | - Monitor out (D-sub 15pin) x 1
- 3D Sync x 1 (Out)
|
| Daya / Power | - AC 100-130V, 50 to 60Hz
- AC 200-240V, 50 to 60Hz
|
| Konsumsi Daya | - 885W (max): Standby Power <0.5W
|
